FOR-A FA-9520 User Manual

92
5-10-17. ANALOG OUT AUDIO
A N A L O G O U T A U D I O
5 89
C H 1 : S I L E N C E
C H 2 : S I L E N C E
C H 3 : S I L E N C E
C H 4 : S I L E N C E
Parameter
Display
Description
CH1 - CH4
SILENCE
OUT
Displays the status of the output audio signal
from the ANALOG AUDIO connector.
SILENCE: Mute signal
OUT: Output signal is present
5-10-18. Dolby OPA AUX
* This menu is displayed only if FA-95D-D option is installed in option slot A.
Dolb y O P A A U X
5 91
INPUT A :LOSS
OUTPUT A : N O N E
R E F E R E N C E A : L O S S
Parameter
Display
Description
INPUT A
LOSS
PCM
NON-PCM
UNKNOWN
Displays status or type of signal input to the
optional Dolby input connector (Dolby IN) in
slot A.
LOSS: No audio signal
PCM: Standard audio signal
NON-PCM: Compressed audio data such as
Dolby E encoded data
UNKNOWN: Unknown signal.
OUTPUT A
PCM
NON-PCM
NONE
Displays status or type of signal output to the
optional Dolby output connectors (Dolby OUT)
in slot A.
PCM: Standard audio signal
NON-PCM: Compressed audio data such as
Dolby E encoded data
NONE: No signal
REFERENCE A
LOSS
525/60
625/50
1080/59i
1080/50i
720/59p
720/50p
1080/23PsF
1080/24PsF
UNKNOWN
Displays signal format of reference signal input
to the optional Dolby REF IN connector in slot
A.
LOSS: No signal
UNKNOWN: Unknown signal format
Menu button
STATUS
OTHER
Menu button
STATUS
OTHER
