FOR-A FA-9520 - Video Input Set

58
5-6-2. VIDEO INPUT SET
V I D E O I N P U T S E T
29
L O S S : B A C K C O L O R
B A C K C O L O R : O F F
S D A S P E C T : 4 : 3
I N S T A T U S :
Parameter
Default
Setting range
Description
LOSS
BACK COLOR
BACK COLOR
AUTO FREEZE
*1
COLOR BAR
OUT DISABLE
Selects an operation for the time the
signal input selected under FS
INPUT SELECT is lost.
BACK COLOR
BLACK
OFF
BLACK
BLUE
RED
MAGENTA
GREEN
CYAN
YELLOW
Select a background color.
SD ASPECT
4:3
4:3
16:9
Selects the aspect ratio for SD input
signals.
This setting is used for fixed aspect
ratio conversions that are performed
when ASPECT in the CONV menu is
set to other than AFD (4:3),
AFD-ALT (4:3), AFD (16:9),
AFD-ALT (16:9), AFD, or AFD-ALT.
IN STATUS
-
SDI1
SDI2
OPTION A
OPTION B
Displays the input video signal in
FS1 or FS2. (Cannot be changed.)
* Settings can be set for FS1 and FS2, respectively.
*1 The selected AUTO FREEZE functions the same as BACK COLOR if SYNCHRO in
section 5-9-1 “FS MODE SET” is set to LINE or AVDL. In such case, the menu is indicated
as “＊AUTO FREEZE”.
 LOSS Operation
If the signal input that is selected under FS INPUT SELECT is lost, the FA-9520 operates in
the selected LOSS mode as follows.
 In BACK COLOR mode
Outputs a matte signal of the color selected under BACK COLOR.
 In AUTO FREEZE mode
Freezes the last image before signal input is lost.
Freezes the field.
Freezes the frame if the lost input signal is of a progressive scan video format such as
720p.
 In COLOR BAR mode
Outputs the SMPTE color bar.
 In OUT DISABLE mode
Does not output any signal from SDI OUT1, 2, 3, 4, COMPOSITE OUT1 or 2.
 In AUTO FREEZE mode
Outputs a black screen if SYNCHRO is set to LINE or AVDL under FS MODE SET
(section 5-9-1).
FS1/LOCK
FS2/LOCK
Menu button
IN SEL
DOWNMIX
