FOR-A FA-9520 - Dolby DECODER GAIN

128
6-10-1-5. Dolby DECODER GAIN
This menu is displayed only if the FA-95D-D or FA-95DE-E option is installed in slot A.
D o l b y D E C G A I N A
185
C H S E L : D E C C H 1
G A I N S E T : 0 . 0 d B
M A S T E R : 0 . 0 d B
Menu names and menu pages for the option in slot B change as shown below.
D o l b y D O W N M I X B
235
Parameter
Default
Setting range
Description
CH SEL
DEC CH1
DEC CH1 – CH8
DolbyDM-L
DolbyDM-R
Selects a signal for gain adjustment.
DEC CH1-CH8: Dolby-decoded PCM
signal
DolbyDM-L/R: Down mixed signal
generated from Dolby-decoded PCM
signal
GAIN SET
0.0 dB
-20.0 - +20.0 dB
(0.1 dB)
*1
Sets gain for the signal selected under
CH SEL.
MASTER
0.0 dB
-20.0 - +20.0 dB
(0.1 dB)
Sets offset for all Dolby-decoded
signals.
*1 If the MASTER setting exceeds the total setting range of individual channels, the alert will
be displayed as *20.0dB or *-20.0dB.
Menu button
VIDEO OP
AUDIO OP
