5-10-10. EMB 1 IN AUDIO
EMB1 IN A U D I O
5 5 1
C H 1 : L O S S
C H 2 : L O S S
C H 3 : L O S S
C H 4 : L O S S
E M B 1 I N A U D I O
5 5 2
C H 5 : L O S S
C H 6 : L O S S
CH 7:LO S S
C H 8 : L O S S
E M B 1 I N A U D I O
5 5 3
C H 9 : L O S S
C H 1 0 : L O S S
C H 1 1 : L O S S
C H 1 2 : L O S S
E M B 1 I N A U D I O
5 5 4
C H 1 3 : L O S S
C H 1 4 : L O S S
C H 1 5 : L O S S
C H 1 6 : L O S S
Parameter
Display
Description
CH1-CH16
LOSS
PCM
SILENCE
NON-PCM
PCM(Async)
SILENCE (Async)
NON-PCM(Async)
UNKNOWN
Displays the status of audio signals CH1 through CH16
embedded to the FS1 video signal.
LOSS: No audio signals
PCM: Normal audio signal (SDI input)
SILENCE: Mute signal (SDI input)
NON-PCM: Compressed audio data such as AC3
PCM (Async) : Normal audio signal (Asynchronous SDI
input)
SILENCE (Async): Mute signal (Asynchronous SDI input)
NON-PCM (Async): Compressed audio data such as AC3
(Asynchronous SDI input)
UNKNOWN: Unidentifiable
.
Menu button
STATUS
OTHER
