71
5-9-3. SD PHASE SET
SD P H A S E S E T
63
H P H A S E : 0 C L K
V P H A S E : 0 L I N E
Parameter
Default
Setting range
(Steps)
Description
H PHASE
*1
0
-864 - 864
( CLK)
Adjusts the horizontal and vertical
phases of the system referring to genlock
signal. This setting is applied to SD
output signals.
V PHASE
*1
0
*2
(FRAME)
1
*2
(LINE, AVDL)
-313 - 313
( LINE)
* Settings can be set for FS1 and FS2, respectively.
*1 The settings are not available if there is no reference signal input. In such case, the menu
as shown below will be displayed.
SD P H A S E S E T
63
H P H A S E : N O T A D J U S T
V P H A S E : N O T A D J U S T
S C P H A S E : N O T A D J U S T
*2 The default value varies depending on the SYNCHRO setting in section 5-9-1 FS MODE
SET and the IN SEL setting in section 5-6-1 FS INPUT SELECT as shown in the below
table. The set value will be reset to its relevant default value whenever the SYNCHRO
setting is changed.
SYNCHRO
IN SEL
Default
FRAME
0
LINE
SDI1, 2
1
COMPOSITE (525/60)
3
COMPOSITE (625/50)
4
COMPONENT (Y/C)
4
COMPONENT (others)
1
AVDL
SDI1, 2
1
COMPOSITE (525/60)
3
COMPOSITE (625/50)
4
COMPONENT (Y/C)
4
COMPONENT (others)
1
FS1/LOCK
FS2/LOCK
Menu button
VIDEO SYS
AUDIO SYS
