5-7-4. ANC DATA EMBED
Allows you to set ancillary data insertion into SDI signal ancillary spaces.
A N C D A T A E M B E D
37
ANC:C E A 6 0 8 C C
F O R M A T : 5 2 5 / 6 0
E M B E D : D I S A B L E
Parameter
Default
Setting range
Description
ANC
CEA608 CC
CEA608 CC
S334-1 CC SD
CEA708 CC HD
S2016-3 AFD
RP186 VI
BT1119 WSS
Selects an ancillary data type to insert.
FORMAT
-
*
Selects a video format that supports the
ancillary data selected under ANC. Only
selectable format will be shown.
EMBED
DISABLE
DISABLE
ENABLE
DISABLE: Does not insert ancillary data
selected under ANC.
ENABLE: Inserts ancillary data selected
under ANC.
* Settings can be set for FS1 and FS2, respectively. See the “Ancillary Data Types” table
below for details.
 Ancillary Data Types
Data type
Description
CEA608 CC
Closed caption data inserted as Y signals into line 21 of 525/60 analog and SDI
signals.
S334-1 CC
Closed caption data inserted as data packets into the ancillary data space of
525/60 SDI signals.
CEA708 CC
Closed caption data inserted as data packets into the ancillary data space of
HD-SDI signals (1080i/720p).
S2016-3 AFD
Aspect ratio data inserted as data packets into the ancillary data space of SD
and HD-SDI signals (525/60, 625/50, 1080i/PsF, 720p, 1080p/(3G)).
RP186 VI
Aspect ratio data inserted into bit 3 of Chroma data in the SD-SDI (525/60,
625/50) V ANC data space.
BT1119 WSS
Aspect ratio data inserted as Y signals into line 23 of 625/50 analog or SDI
signals.
