FOR-A FA-9520 - Video in Status

82
5-10-2. VIDEO IN STATUS
V I D E O I N S T A T U S
502
FS1 ( S D I 1 ) ： 1 0 8 0 / 5 9 i
F S 1 ( S D I 2 ) ： 5 2 5 / 6 0
C O M P O S I T E : 5 2 5 / 6 0
R E F E R E N C E : 5 2 5 / 6 0
Parameter
Display
Description
FS1(SDI1)
LOSS
525/60
625/50
1080/59i
1080/50i
720/59p
720/50p
1080/23PsF
1080/24PsF
1080/59p
1080/50p
BY-PASS
UNKNOWN
Displays the video format of the SDI1 input signal.
Displays “LOSS” if there is no input signal.
Displays “UNKNOWN” if there is an unsupported input
signal.
Displays video format, LOSS, or UNKNOWN only if
FS1 IN SEL or FS2 IN SEL is set to SDI1 in the FS
INPUT SELECT menu (section 5-6-1). Otherwise,
“-----“ is displayed.
FS2(SDI2)
LOSS
525/60
625/50
1080/59i
1080/50i
720/59p
720/50p
1080/23PsF
1080/24PsF
1080/59p
1080/50p
BY-PASS
UNKNOWN
-----
Displays the video format of the SDI2 input signal.
Displays “LOSS” if there is no input signal.
Displays “UNKNOWN” if there is an unsupported input
signal.
Displays video format, LOSS, or UNKNOWN only if
FS1 IN SEL or FS2 IN SEL is set to SDI2 in the FS
INPUT SELECT menu (section 5-6-1). Otherwise,
“-----“ is displayed.
COMPOSITE
LOSS
525/60
625/50
BY-PASS
Displays the video format of the COMPOSITE input
signal.
Displays “LOSS” if there is no input signal.
REFERENCE
LOSS
525/60
625/50
1080/59i
1080/50i
720/59p
720/50p
1080/23PsF
1080/24PsF
PAL-M
*1
UNKNOWN
Displays the video format of the genlock input signal.
Displays “LOSS” if there is no input signal.
Displays “UNKNOWN” if there is an unsupported input
signal.
*1 Shown when PAL-M Mode in the 5-9-15 “COMPOSITE SET2” is set to ENABLE, and an
input signal in GENLOCK IN connector is 525/60 or PAL-M signal.
Menu button
STATUS
OTHER
