6-5-2. EMB2 OUT REMAP
E M B 2 O U T R E M A P
142
C H S E L : C H 1
A S S I G N : E M B 2 C H 1
F R O M : S D I I N 2
Parameter
Default
Setting range
Description
CH SEL
CH1
CH1 - CH16
Selects an FS2 audio channel to
embed audio signal from CH1
through 16.
ASSIGN
EMB2 CH1-16
EMB1 CH1-16
EMB2 CH1-16
AES CH1-8
*1
ANALOG CH1-4
DOWN MIX1-L
DOWN MIX1-R
DOWN MIX2-L
DOWN MIX2-R
500Hz TONE
1KHz TONE
SILENCE
Dolby DECA CH1-8
*2
Dolby DMA-L
*2
Dolby DMA- R
*2
Dolby ENCA CH1-2
*3
Dolby DECB CH1-8
*4
Dolby DMB-L
*4
Dolby DMB- R
*4
Dolby ENCB CH1-2
*5
Selects an audio signal to embed
into the FS2 audio channel
selected under CH SEL.
LOUD1A
*6
LOUD2A
*6
LOUD1B
*7
LOUD2B
*7
L
R
C
LFE
Ls
Rs
FROM
-
SDI IN1
SDI IN2
-----
Displays the input signal from which
the selected embedded audio signal
is input, if ASSIGN is set to one
among EMB1 CH1 through 16 and
EMB2 CH1 through 16.
*1 If the AES connector is set to be used for input, the selected AES channel will be displayed
with an “＊“ as “＊AES CH1“ and no audio signal will be output. To change AES I/O
settings, see section 6-2-4. “AES I/O SETUP“ for details.
*2 Not shown if the FA-95D-D or FA-95DE-E option is not installed in option slot A.
*3 Not shown if the FA-95DE-E option is not installed in option slot A.
*4 Not shown if the FA-95D-D or FA-95DE-E option is not installed in option slot B.
*5 Not shown if the FA-95DE-E option is not installed in option slot B.
*6 Not shown if the FA-95ALA option is not installed in option slot A.
*7 Not shown if the FA-95ALA option is not installed in option slot B.
 Auto Channel Pairing for NON-PCM Audio Inputs
The FA-9520 recognizes NON-PCM audio input signals in L/R channel pair units, and adjusts
assignments according to the signal selected for the L channel.
L/R channel pairs are, such as CH1 and CH2, CH3 and CH4......CH15 and CH16 as an
example in EMB1.
The channel assignments that are changed by the adjustment will be shown with “＊” as
“CH1:＊EMB1 CH1”.
Menu button
PROCESS
SDI AUDIO
