FOR-A FA-9520 - Aes out Mono; Aes I;O Setup

105
6-2-3. AES OUT MONO
AES O U T MONO
1 13
C H S E L : C H 1 / 2
M O N O S U M : D I S A B L E
Parameter
Default
Setting range
Description
CH SEL
CH1/2
CH1/2 - 7/8
Selects a stereo pair of AES output
audio channels.
MONO SUM
DISABLE
DISABLE
ENABLE
ENABLE: Outputs the stereo pair
channels that are selected under CH
SEL as a mono sum.
(The signals of the selected pair
channels are added and divided by
two to output from each channel.)
If the AES connector is set to be used for input, the menu display for the selected AES output
audio channel appears as ＊CH1. See section 6-2-4 “AES I/O SETUP” and change the
setting if necessary.
6-2-4. AES I/O SETUP
A E S I / O S E T U P
1 14
AES1- 4 I / O : I N P U T
AES5- 8 I / O : I N P U T
Parameter
Default
Setting range
Description
AES1 - 4
INPUT
INPUT
OUTPUT
INPUT: AES1/2, and 3/4 connectors are
set to be input connectors.
OUTPUT: AES1/2, and 3/4 connectors
are set to be output connectors.
AES5 - 8
INPUT
INPUT
OUTPUT
INPUT: AES5/6, and 7/8 connectors are
set to be input connectors.
OUTPUT: AES5/6, and 7/8 connectors
are set to be output connectors.
All connectors are set as input connectors and this menu is not displayed if the FA-95DACBL
option is installed.
Menu button
C C
AES AUDIO
Menu button
C C
AES AUDIO
