FOR-A FA-9520 - Trap Setting

232
9-8-4. TRAP SETTING
Allows you to control SNMP trap transmission. Check the check box of a trap to be sent, then
click Submit. Uncheck to stop sending. See the TRAP List in section 18 “About SNMP (Simple
Network Management Protocol)” for details.
 Unit Trap
Allows you to select whether to send fan and power unit alarm traps.
Default is to send.
Item
Description
FAN1
Check to send an alarm trap for Fan1.
FAN2
Check to send an alarm trap for Fan2.
Power1
*1
Check to send an alarm trap for Power1.
Power2
*1
Check to send an alarm trap for Power2.
*1 Not shown if the FA-95PS option is not installed.
 Video Trap
Allows you to select whether to send traps for Input/output video signal changes.
Default is not to send.
Item
Description
SDI 1 In
Check to send a trap for SDI In 1.
SDI 2 In
Check to send a trap for SDI In 2.
Composite In
Check to send a trap for Composite In.
Reference
Check to send a trap for Reference.
SDI 1/2 Out
Check to send a trap for SDI Out 1/2.
SDI 3/4 Out
Check to send a trap for SDI Out 3/4.
Composite Out
Check to send a trap for Composite Out.
FA-95AIO Option A In
*1
Check to send a trap for FA-95AIO Option A input video.
FA-95AIO Option A Out
*1
Check to send a trap for FA-95AIO Option A output video.
FA-95AIO Option B In
*2
Check to send a trap for FA-95AIO Option B input video.
FA-95AIO Option B Out
*2
Check to send a trap for FA-95AIO Option B output video.
*1 Shown if the FA-95AIO option is installed in option slot A.
*2 Shown if the FA-95AIO option is installed in option slot B.
 Audio Trap
Allows you to select whether to send traps for Input/output audio signal changes.
No traps are sent in the default setting.
Item
Description
SDI 1/2 OutCH1-16
Check to send a trap for SDI 1/2 audio output channels.
SDI 3/4 OutCH1-16
Check to send a trap for SDI 3/4 audio output channels.
AES Out CH1-8
Check to send a trap for AES audio output channels.
Analog Out CH1-4
Check to send a trap for analog audio output channels.
