5-10-8. AUDIO OUTPUT1
A U D I O O U T P U T 1
5 46
S D I 1 / 2 ( E M B 1 ) C H 1 - 16
P P P P N N N N S S S S ----
S D I 3 / 4 ( E M B 2 ) C H 1 - 16
P P P P N N N N S S S S ----
Parameter
Display
Description
SDI 1/2 (EMB1)
CH1-16
P
S
N
-
B
Displays information on SDI 1/2 output audio signals CH1
through 16 in 16 characters on the 2nd line from top.
P (PCM): Normal audio signal
S (Silence): Mute signal
N (NON-PCM): Compressed audio data such as AC3
-: No embedded audio
B (BY-PASS): Video signal is bypassed and output.
*1
SDI 3/4 (EMB2)
CH1-16
P
S
N
-
B
Displays information on SDI 3/4 output audio signals CH1
through 16 in 16 characters on the 4th line from top.
P (PCM): Normal audio signal
S (Silence): Mute signal
N (NON-PCM): Compressed audio data such as AC3
-: No embedded audio
B (BY-PASS): Video signal is bypassed and output.
*1
*1 See section 5-3-1. “CONV MODE” for details on SDI output signal by-pass settings.
5-10-9. AUDIO OUTPUT3
A U D I O O U T P U T 3
548
A E S C H 1 - 8
PPSS NN--
A N A L O G C H 1 - 4
PP--
Parameter
Display
Description
AES CH1-8
P
S
N
I
Displays information on AES output audio signals CH1
through 8 in 8 characters on the 2nd line from top.
P (PCM): Normal audio signal
S (Silence): Mute signal
N (NON-PCM): Compressed audio data such as AC3
I (Input: AES connector is set for input use.
*1
ANALOG CH1-4
P
-
Displays information on ANALOG output audio signals
CH1 through 4 in 4 characters on the 4th line from top.
P (Present): An audio signal is present
-: No embedded audio
S (Silence): Mute signal
*1 See section 6-2-4. “AES I/O SETUP” for details on DIGITAL AUDIO connector I/O settings.
Menu button
STATUS
OTHER
Menu button
STATUS
OTHER
