FOR-A FA-9520 - VIDEO INPUT SELECT (IN SEL)

57
5-6. VIDEO INPUT SELECT (IN SEL)
Allows you to select input video signals, and select the operation for when signal input is lost.
5-6-1. FS INPUT SELECT
F S I N P U T S E L E C T
28
F S 1 I N S E L : S D I 1
F S 2 I N S E L : S D I 2
Parameter
Default
Setting range
Description
FS1 IN SEL
SDI1
SDI1
SDI2
COMPOSITE
OPTION A
*1
OPTION B
*2
Selects an input video signal for
FS1.
OPTION A: Input signal from the
FA-95AIO in option slot A.
OPTION B: Input signal from the
FA-95AIO in option slot B.
FS2 IN SEL
SDI2
SDI1
SDI2
COMPOSITE
OPTION A
*1
OPTION B
*2
Selects an input video signal for
FS2.
OPTION A: Input signal from the
FA-95AIO in option slot A.
OPTION B: Input signal from the
FA-95AIO in option slot B.
*1 Selectable only if the FA-95AIO option is installed in option slot A.
*2 Selectable only if the FA-95AIO option is installed in option slot B.
COMPOSITE, OPTION A, or OPTION B cannot be selected for both FS1 and FS2.
If you wish to select COMPOSITE, OPTION A, or OPTION B for either FS while the same
signal is selected for the other FS, reset the current COMPOSITE, OPTION A, or OPTION B
selection to SDI 1 or 2 first, then select a signal as you wish.
If COMPOSITE, OPTION A or OPTION B is selected for both FS1 IN SEL and FS2 IN SEL,
the “CANNOT ASSIGN SIMUL COMPOSITE, FA-95AIO” alert message will appear.
Menu button
IN SEL
DOWNMIX
