FOR-A FA-9520 - OUTPUT GAIN CONTROL

108
6-4. OUTPUT GAIN CONTROL
Allows you to adjust audio signal output gain.
6-4-1. MASTER OUT GAIN
M A S T E R O U T G A I N
131
G A I N S E T : 0 . 0 d B
M U T E : O F F
Parameter
Default
Setting range
(Steps)
Description
GAIN SET
0.0dB
-20.0 - +20.0 dB
(0.1 dB)
Sets audio gain for the signal
selected under CH SEL.
MUTE
OFF
OFF
ON
ON: Mutes all audio channels.
6-4-2. EMB1 OUT GAIN
EMB1 O U T G A I N
132
C H S E L : C H 1
G A I N S E T : 0 . 0 d B
M A S T E R : 0 . 0 d B
M A S T E R M U T E : O F F
Parameter
Default
Setting range
(Steps)
Description
CH SEL
CH1
CH1 - 16
Selects an audio channel from
among FS1 embedded audio
channels CH1 through 16 for
which to set audio gain.
GAIN SET
0.0dB
-20.0 - +20.0 dB
(0.1 dB)
*1
Sets audio output gain for the
signal selected under CH SEL.
MASTER
－
-20.0 - +20.0 dB
(0.1 dB)
Sets the offset to audio output
gain for all audio channels CH1
through 16 in FS1.
MUTE
OFF
OFF
ON
ON: Mutes all embedded audio
channels in FS1.
*1 The total value of GAIN SET and MASTER should not exceed the setting range. If the
range is exceeded, the alert will be displayed as *20.0dB or *-20.0dB.
Menu button
CONV2
MASTER
Menu button
CONV2
MASTER
