FOR-A FA-9520 User Manual

52
5-4-4. USER1, 2 AREA SET
Selecting USER1 (or 2) AREA for AREA in the AVO SETTING menu opens the USER1, 2
AREA SET menus.
U S E R 1 A R E A S E T
1 8
S T A R T H : 0 P I X E L
S T A R T V : 0 L I N E
H S I Z E : 3 6 0 P I X E L
V S I Z E : 3 6 0 L I N E
To set the sample area, set the start point and the size.
Parameter
Default
Setting
range
Description
START H
0 Pixel
Variable
(2Pixel)
Specifies the horizontal start point.
START V
0 Line
Variable
(2Line)
Specifies the vertical start point.
H SIZE
360
Variable
(2Pixel)
Specifies the horizontal size (distance) from the
start point.
V SIZE
360
Variable
(2Line)
Specifies the vertical size (distance) from the
start point.
IMPORTANT
The sample area should be set within the effective lines and pixels. Otherwise, the
sample area will automatically revert to their default values. Be particularly careful in
the following cases.
- When the video format is changed to SDTV after the sample area has been set.
- When the sample area settings are changed by loading an event.
While the USER 1, 2 AREA SET setting menu is open and the AREA is changed via
web browser or the connected FA-95RU to other than USER AREAs 1 and 2 in the
AVO SETTING menu (5-4-1), the menu will change to display the AVO SETTING
menu (5-4-1).
Sample
area
V SIZE
H SIZE
(START V , START H)
Default setting of sample area
in 1080/59.94i.
Menu button
AVO
MAPPING
