158
9-2-2-2. User 1 - 5 LEVEL SET
Clicking Set User on the Auto Video Optimizer dialog box opens the User1 - 5 setting
dialog box.
After completing the settings, click Close to close the dialog box.
Click Refresh to update the settings.
Click Unity to reset to the default settings.
Click to increase the value by the smallest steps.
Click to decrease the value by the smallest steps.
The Level drop-down menu in the AVO dialog box has five options of user settings, User 1
through 5. Each User1 – 5 is composed of four level settings such as In White Level, In
Black Level, Target White Level, and Target Black Level. The default settings of user
settings User 1 through 5 are the same as those for Darker, Dark, Standard, Bright, and
Brighter respectively. The desirable level settings are easily obtained by adjusting values
from the default values.
USER1 – 5 Default Settings
SELECT LEVEL (Adjustment level)
