5-10-20. AFD IN STATUS
Displays the state of FS1/FS2 AFD detection.
 When detecting AFD in input S2016-3
AFD1 I N S T A T U S
6 0 1
D E T E C T : S 2 0 1 6 - 3
A F D : 0 2 A R : 0
4 : 3 L 1 6 : 9 T
D : 1 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0
AFD: Active Format Description is displayed in hexadecimal format.
AR: Aspect Ratio is displayed in binary format (0=4:3, 1=16:9)
The detected AFD type is shown on the third row.
D: Detected Data1-8 are displayed in hexadecimal format.
 When detecting AFD in input RP186 VI
AFD1 I N S T A T U S
6 0 1
DETECT： R P 1 8 6 V I
AFD： 02 SS： 00
4 : 3 L 1 6 : 9 T
D1： 10 D2： 00 D3： 00
Displays the status of RP186 VI (Video Index) Class1.
AFD: Active Format Description is displayed in hexadecimal format.
SS: Scanning System is displayed in hexadecimal format.
The detected AFD type is shown on the third row.
D1-D3: Detected Data are displayed in hexadecimal format.
 When detecting AFD in input BT1119-2 WSS
AFD1 I N S T A T U S
6 0 1
DETECT： B T 1 1 1 9 W S S
AFD:01
B O X 1 4 : 9 C E N T E R
BIT13- 0 : 0 0 0 0
Displays the status of BT1119-2 WSS (Wide Screen Signaling).
AFD: Active Format Description is displayed in hexadecimal format.
The detected AFD type is shown on the third row.
BIT13-0: Detected Bits 13 – 0 are displayed in hexadecimal format.

See section 20-6“AFD Code Abbreviations” for details on AFD types.
5-10-21. ANC1 IN STATUS
ANC1 I N S T A T U S
6 1 1
C E A 6 0 8 : P R E S E N T L : 2 1
WSS:A B S E N T
VI:P R E S E N T L : 1 4 / 2 7 7
Displays the state of CEA608, WSS, and VI ancillary data in the FS1/FS2 input signal
luminance component.
The line number in which the ancillary data is in is displayed.
Menu button
STATUS
OTHER
Menu button
STATUS
OTHER
FS1/LOCK
FS2/LOCK
