5-10-12. AES IN AUDIO
A E S I N A U D I O
5 59
C H 1 : L O S S
C H 2 : L O S S
C H 3 : L O S S
C H 4 : L O S S
A E S I N A U D I O
5 60
C H 5 : L O S S
C H 6 : L O S S
C H 7 : L O S S
C H 8 : L O S S
Parameter
Display
Description
CH1 - CH8
LOSS
PCM 48kHz
PCM 44.1kHz
PCM 32kHz
PCM Other
SILENCE 48kHz
SILENCE 44.1kHz
SILENCE 32kHz
SILENCE Other
NON-PCM
OUTPUT SETTING
Displays the status of the audio signal input to the
DIGITAL AUDIO IO connectors.
LOSS: No audio signals
PCM 48kHz: Normal audio signal (approx. 48kHz)
PCM 44.1kHz: Normal audio signal (approx. 44.1kHz)
PCM 32kHz: Normal audio signal (approx. 32kHz)
PCM Other: Normal audio signal (Non AES input)
SILENCE 48kHz: Mute signal (approx. 48kHz)
SILENCE 44.1kHz: Mute signal (approx. 44.1kHz)
SILENCE 32kHz: Mute signal (approx. 32kHz)
SILENCE Other: Mute signal (Non AES input)
NON-PCM: Compressed audio data such as AC3
OUTPUT SETTING: Connector is set to output
5-10-13. ANALOG IN AUDIO
A N A L O G I N A U D I O
5 61
C H 1 : L O S S
C H 2 : L O S S
C H 3 : L O S S
C H 4 : L O S S
Parameter
Display
Description
CH1 - CH4
LOSS
IN
Displays the status of the input audio signal in
the ANALOG AUDIO connector.
LOSS: No audio signal is present.
IN: An audio signal is present.
Menu button
STATUS
OTHER
Menu button
STATUS
OTHER
