5. VIDEO Menus
Make the menu buttons light up green using the VIDEO/AUDIO button.
(Pressing the button while the buttons are lit orange turns the lights green.)
Then the menus displayed on the upper row on each menu button can be selected.
5-1. VIDEO PROC AMP (PROCESS)
V I D E O P R O C A M P
1
V I D E O L E V E L : 1 0 0 . 0 %
C H R O M A L E V E L : 1 0 0 . 0 %
S E T U P / B L A C K : 0 . 0 %
HUE : 0 . 0 °
Parameter
Default
Setting range
(Steps)
Description
VIDEO LEVEL
100.0%
0.0 - 200.0%
(0.1％)
Adjusts the video level.
CHROMA LEVEL
100.0%
0.0 - 200.0%
(0.1％)
Adjusts the chrominance level.
SETUP/BLACK
0.0%
-20.0 - 100.0%
(0.1％)
Adjusts the black level.
HUE
0.0°
-179.8 - 180.0°
(0.2°)
Adjusts the color phase.
* Settings can be set for FS1 and FS2 separately.
5-2. COLOR CORRECTOR (C.C.)
Allows you to adjust the Color corrector settings.
5-2-1. WHITE LEVEL
W H I T E L E V E L
2
R E D : 1 0 0 . 0 %
G R E E N : 1 0 0 . 0 %
B L U E : 1 0 0 . 0 %
G R O U P A D J U S T
Parameter
Default
Setting range
(Steps)
Description
RED, GREEN, BLUE
(RGB White Level)
100.0%
0.0 - 200.0%
(0.5%)
Adjusts the white level of R, G,
and B components separately.
GROUP ADJUST
(Group Adjustment)
100.0%
0.0 - 200.0%
(0.5%)
Adjusts the white level of R, G,
and B components all together
while retaining the proportion of
the separately adjusted levels.
* Settings can be set for FS1 and FS2 separately.
If MODE is set to SEPIA in the COLOR CORRECT (C.C.) menu (5-2-4), the menu as shown
below will be displayed.
W H I T E L E V E L
2
R E D : N O T A D J U S T
G R E E N : N O T A D J U S T
B L U E : N O T A D J U S T
C . C M O D E I S S E P I A
*1
*1 If AVO is enabled, the message “AVO IS USING IT” will be displayed.
Menu button
VIDEO
AUDIO
Menu button
PROCESS
SDI AUDIO
FS1/LOCK
FS2/LOCK
Menu button
CC
AES AUDIO
FS1/LOCK
FS2/LOCK
