FOR-A FA-9520 - Page 36

36
 Example 3: Setting VIDEO PROCESS AMP for FS1 and FS2 simultaneously
V I D E O P R O C A M P
FS1
V I D E O L E V E L : 1 0 0 . 0 %
C H R O M A L E V E L : 1 0 0 . 0 %
SETU P / B L A C K : 0 . 0 %
HUE : 0 . 0 °
1. Press the PROCESS/SDI AUDIO button to open the VIDEO PROCESS AMP menu. Press
the FS2/LOCK button for it to light green.
2. Press the FS1/LOCK and FS2/LOCK buttons simultaneously. One button will blink and
another will light green. Press the FS1/LOCK button for it to light green. In the VIDEO
PROCESS AMP menu, FS1 setting values are displayed. (“FS1” or “FS2” will be displayed
in the space a page number is usually displayed.) Pressing the FS2/LOCK button will light
the button green, and display FS2 setting values in the menu.
3. Turn control knobs F1 to F4 to change setting values. The same amount of setting values
are changed for FS1 and FS2 simultaneously.
4. To exit simultaneous setting mode, simultaneously press FS1/LOCK and FS2/LOCK
buttons again. One button will go off and the other will light green allowing setting changes
only for the corresponding FS.
IMPORTANT
FS1 and FS2 cannot be changed simultaneously by pressing FS1/LOCK and
FS2/LOCK buttons at the same time in the following cases:
1. When the Color correction mode for either FS1 or FS2 is set to SEPIA. See
section 5-2-4. “COLOR CORRECT (C.C.)” for details on Color correction mode.
2. When FS1 AVO mode is set to AUTO or HOLD. See section 5-4-1 “AVO SETTING”
for details on AVO modes.
NOTE
In FS1/FS2 simultaneous setting mode, each control knob applies identical
adjustment values to both FS1 and FS2.
Menus supported for simultaneous setting mode are shown with “⊚” in the menu list in
section 4-2-2. “Menu Buttons”.
 Example 4: Disabling FS1/FS2 settings or front panel buttons
To prevent unexpected operation, settings for FS1 or FS2, or front panel buttons can be
disabled.
Button light color
Inhibition of
Setting procedure
Cancelling procedure
FS1/LOCK
FS2/LOCK
Orange
Green
FS1 settings
Hold down the
FS1/LOCK button > 3
sec.
Hold down the
FS1/LOCK button > 3
sec.
Green
Orange
FS2 settings
Hold down the
FS2/LOCK button >t
3 sec.
Hold down the
FS2/LOCK button > 3
sec.
Orange
Orange
Front panel
buttons
Hold down both
FS1/LOCK and
FS2/LOCK buttons >
3 sec for them to light
orange.
Hold down either the
FS1/LOCK or
FS2/LOCK button > 3
sec for either one to
lock.
* When either FS setting is disabled, the menus will display settings of another non-disabled
FS.
* When front panel buttons are disabled, the last displayed menu will remain displayed. All
operations except unlocking FS1 or FS2 are disabled.
Menu button
PROCESS
SDI AUDIO
Lit green
FS1/LOCK
Blinking green
FS2/LOCK
