6-4-5. ANALOG OUT GAIN
A N A L O G O U T G A I N
1 35
C H S E L : C H 1
G A I N S E T : 0 . 0 d B
M A S T E R : 0 . 0 d B
M U T E : O F F
Parameter
Default
Setting range
(Steps)
Description
CH SEL
CH1
CH1 - CH4
Selects an analog audio output
channel for which to set the input
gain from channels CH1 to CH4.
GAIN SET
0.0dB
-20.0 - +20.0 dB
(0.1 dB)
Sets the output gain for the analog
audio output signal that is selected
under CH SEL.
MASTER
0.0 dB
-20.0 - +20.0 dB
(0.1 dB)
Sets the offset to the output gain
for all analog audio channels CH1
to CH4.
MUTE
OFF
OFF
ON
ON: Mutes all analog audio
channels.
*1 The total value of GAIN SET and MASTER should not exceed the setting range. If the
range is exceeded, the alert will be displayed as *20.0dB or *-20.0dB.
Menu button
CONV1
ANALOG
