FOR-A FA-9520 User Manual

144
7-6. GPI SETTING
G P I S E T T I N G
296
GPI1- 7 S E L : G P I 1
I N / O U T S E L : I N P U T
A S S I G N : N O N E
Parameter
Default
Setting range
Description
GPI1-7 SEL
GPI1
GPI1-7
Selects a GPI pin of the
REMOTE port.
IN/OUT SEL
*1
INPUT
INPUT
OUTPUT
Selects whether to use the
GPI pin that is selected
under GPI1-7 SEL for input
or tally output.
ASSIGN
NONE
In case IN/OUT SEL is set to INPUT
*2
NONE
DEFAULT EVENT1 - 100
Assigns a function to the
GPI pin that is selected
under GPI1-7 SEL
according to the selection
under IN/OUT SEL.
BY-PASS
(SDI1)
(SDI2)
(VBS)
FS1/FS2
FREEZE
FULL CB
75% CB
SMPTE CB
RAMP
SDI1
SDI2
OP A
*4
OP B
*5
COMPOSITE
KEYER
LOAD 1-7
*7
EXT AUDIO
DEFAULT EVENT1 to 100
LOUD1
LOUD2
A START
*8
B START
*9
A CLEAR
*8
B CLEAR
*9
BY-PASS (OP A)
*4
BY-PASS (OP B)
*5
In case IN/OUT SEL is set to OUTPUT
NONE
REF IN
FAN ALARM
DC POWER1
*6
DC POWER2
*6
FS1/FS2
FREEZE
VIDEO IN
SDI1
SDI2
OP A
*4
OP B
*5
COMPOSITE
KEYER
LOUD 1
LOUD 2
A CTRL
*8
B CTRL
*9
LOGO ID
1 - 7
1 - 256
Selects a logo ID for the
selected FS1 LOAD 1 - 7, or
FS2 LOAD 1 – 7.
*1 Whenever the IN/OUT SEL setting is changed, ASSIGN is reset to NONE. Reset ASSIGN.
*2 The input functions consist of pulse mode and level mode functions. See the following “◆INPUT
FUNCTION” for details.
*3 Details of the output functions are shown in the “◆OUTPUT FUNCTION” on the next page.
Power 1 and 2 are selectable if the FA-95PS option is installed.
Menu button
STATUS
OTHER
