FOR-A FA-9520 User Manual

54
5-5. CLIP (VIDEO CLIP)
5-5-1. YPbPr/RGB CLIP
Y P b P r / R G B C L I P
2 5
C L I P M O D E : O F F
Parameter
Default
Setting range
Description
CLIP MODE
(Clip Mode)
OFF
OFF,
YPbPr CLIP,
RGB CLIP
Selects a mode whether to clip
signals in the YPbPr color space or
RGB color space.
* Settings can be set for FS1 and FS2, respectively.
 YPbPr CLIP
Y P b P r / R G B C L I P
2 5
M O D E : Y P b P r C L I P
Y W H I T E : 1 0 9 . 0 %
Y B L A C K : - 7 . 5 %
C H R O M A : 1 1 1 . 0 %
Parameter
Default
Setting range
(Steps)
Description
Y WHITE
(Y White Clip)
109.0%
50.0 - 109.0%
(0.5％)
Sets the Y signal upper threshold.
Y BLACK
(Y Black Clip)
-7.5％
-7.5 - 50.0%
(0.5％)
Sets the Y signal lower threshold.
CHROMA
(YPbPr Chroma Clip)
111.0％
50.0 - 111.0%
(0.5％)
Sets both the upper and lower
thresholds of PbPr signals.
 RGB CLIP
Y P b P r / R G B C L I P
2 5
M O D E : R G B C L I P
W H I T E : 3 0 0 . 0 %
BLACK:- 2 0 0 . 0 %
Parameter
Default
Setting range
(Steps)
Description
WHITE
(RGB White Clip)
300.0%
50 - 300%
(0.5％)
Sets the upper threshold of RGB
color space.
BLACK
(RGB Black Clip)
-200.0％
-200 - 50%
(0.5％)
Sets the lower threshold of RGB
color space.
FS1/LOCK
FS2/LOCK
Menu button
CLIP
DELAY
