42
5-3-2. CONV Conversion Table
Possible Conversions in CONV for Input Signal Formats and Mode Selections
(Common for FS1 and FS2)
In the conversions to the formats indicated as (BY-PASS), the CONV SIZE/POS, CONV CROPPING,
CONV IMPROVE, and CONV SIDE RGB settings cannot be changed.
5-3-3. CONV SIZE/POS
Adjusts the width of the video
displayed on the monitor.
*1
Adjusts the height of the video
displayed on the monitor.
*1
H POS
(Horizontal Position)
Adjusts the horizontal position of
the video displayed on the monitor.
V POS
(Vertical Position)
Adjusts the vertical position of the
video displayed on the monitor.
* Settings can be set for FS1 and FS2, respectively.
*1 If the size is made smaller than the original size, set the background color under CONV
SIDE RGB (see section 5-3-6).
*2 The following parameters interact with each other. When you change one of their setting
values, setting ranges of other parameters will also change.
SYNC FRMT Parameter in FS MODE SET (see section 5-9-1).
CONV parameter in CONV MODE (see section 5-3-1).
If the CONV mode is set to BY-PASS, the CONV SIZE/POS setting cannot be changed. Also,
it cannot be changed if the conversion is set to the formats indicated as (BY-PASS) in the
CONV Conversion Table (see section 5-3-2). In both cases, the menu as shown below will be
displayed.
H S I Z E : N O T A D J U S T
V S I Z E : N O T A D J U S T
H P O S : N O T A D J U S T
V P O S : N O T A D J U S T
