FOR-A FA-9520 - FA-9520 Ancillary Data Packet Name List

259
19. FA-9520 Ancillary Data Packet Name List
FA-9520 Indication
DID/SDID
(hexadecimal)
Description
S353MMPEG(V)
08/08
MPEG recoding data, VANC space (Picture rate information)
S353M MPEG(H)
08/0C
MPEG recoding data, HANC space (Other part of recording data set)
S305M SD-SDTI
40/01
ARIB STD-B17 Serial Data Transport Interface for Television
S305M HD-SDTI
40/02
ITU-R BT.1557, SMPTE 348M for HD-SDTI
S427 Lk Enc 1
40/04
SMPTE 427 Link Encryption Message 1
S427 Lk Enc 2
40/05
SMPTE 427 Link Encryption Message 2
S427 Lk Meta
40/06
SMPTE 427 Link Encryption Metadata
S352M VPID
41/01
BTA S-004C Video Payload Identification for Digital Interfaces
S2016-3 AFD-Bar
41/05
SMPTE 2016-3 AFD and Bar Data
S2016-4 PanScan
41/06
SMPTE 2016-3 Pan-Scan Data
RP2010 SCTE 104
41/07
SMPTE 2010 ANSI/SCTE 104 messages
S2031 SCTE VBI
41/08
SMPTE 2010 DVB/SCTE VBI data
ITU-R BT.1685
43/01
ITU-R BT.1685 Inter-station control data packets
RDD8 OP47(SDP)
43/02
SMPTE RDD 8 Subtitling Distribution packet(SDP)
RDD8 OP47(Mult)
43/03
SMPTE RDD 8 Transport of ANC packet in an ANC Multipacket
S346M
43/13
Time Division Multiplexing Video Signals and Generic Data over HD-SDI
RP214 KLV(V)
44/04
SMPTE RP 214 KLV Metadata transport in VANC space
RP214 KLV(H)
44/14
SMPTE RP 214 KLV Metadata transport in HANC space
RP223 UMID
44/44
SMPTE RP 223 Packing UMID and Program Identification Label
Data into SMPTE 291M Ancillary Data Packets
S2020 Aud
45/01
SMPTE 2020-1 Compressed Audio Metadata
S2020AudPr1/2
45/02
SMPTE 2020-1 Compressed Audio Metadata
S2020AudPr3/4
45/03
SMPTE 2020-1 Compressed Audio Metadata
S2020AudPr5/6
45/04
SMPTE 2020-1 Compressed Audio Metadata
S2020AudPr7/8
45/05
SMPTE 2020-1 Compressed Audio Metadata
S2020AudPr9/10
45/06
SMPTE 2020-1 Compressed Audio Metadata
S2020AudPr11/12
45/07
SMPTE 2020-1 Compressed Audio Metadata
S2020AudPr13/14
45/08
SMPTE 2020-1 Compressed Audio Metadata
S2020 AudP15/16
45/09
SMPTE 2020-1 Compressed Audio Metadata
RP215 Film Xfer
51/01
RP215 Film Codes in VANC space
ARIB TRB.18
5F/CF
Color information packets standardized in ARIB TR-B18 “Color Frame
Information for Component Interface of 525/60 Television System”
ARIB B.37
1D0
・
・
2DB
Closed caption data packets (for expansion) standardized in ARIB
STD-B37 “Structure and Operation of Closed Caption Data Conveyed by
Ancillary Data Packets”
ARIB B.37 Mob
5F/DC
Caption format used in digital television broadcasting for mobile receivers
standardized in ARIB STD-B37“Structure and Operation of Closed Caption
Data Conveyed by Ancillary Data Packets”
ARIB B.37 Ana
5F/DD
Analog signal closed caption data packets standardized in ARIB STD-B37
“Structure and Operation of Closed Caption Data Conveyed by Ancillary
Data Packets”
ARIB B.37 SD
5F/DE
SD signal closed caption data packets standardized in ARIB STD-B37
“Structure and Operation of Closed Caption Data Conveyed by Ancillary
Data Packets”
ARIB B.37 HD
5F/DF
HD signal closed caption data packets standardized in ARIB STD-B37
“Structure and Operation of Closed Caption Data Conveyed by Ancillary
Data Packets”
ARIB TR-B.22
5F/E0
HD ancillary data packet for transmission standardized in ARIB TR-B22
“Operational Guidelines for Transport of the Ancillary Data for HDTV
Contribution”
ARIB TRB23(1)
5F/FA
Dummy packet standardized in ARIB TR-B23 ” Operational Guidelines for
Ancillary Data in Inter-Stationary Information Exchange”
ARIB TRB23(2)
5F/FB
User data 2 in user data packets standardized in ARIB TR-B23
“ Operational Guidelines for Ancillary Data in Inter-Stationary Information
Exchange”
