FOR-A FA-9520 - Analog out Mono; Analog in System

107
6-3-4. ANALOG OUT MONO
A N A L O G O U T M O N O
124
C H S E L : C H 1 / 2
M O N O S U M : D I S A B L E
Parameter
Default
Setting range
Description
CH SEL
CH1/2
CH1/2-3/4
Selects a stereo pair of analog
audio output channels.
MONO SUM
DISABLE
DISABLE
ENABLE
ENABLE: Outputs the stereo pair
channels that are selected under
CH SEL as a mono sum.
(The signals of the selected pair
channels are added and divided
by two to output from each
channel.)
6-3-5. ANALOG IN SYSTEM
A N A L O G I N S Y S T E M
125
T E R M I N A L S E T : 6 0 0 Ω
S I L E N C E T I M E : 2 s e c
S I L E N C E L V L : - 72dBFS
Parameter
Default
Setting range
(Steps)
Description
TERMINAL SET
600Ω
600Ω
Hi-Z
Selects how to terminate the
analog inputs 1/2 and 3/4.
600Ω: 600Ω termination
Hi-Z: High-impedance
SILENCE TIME
2sec
1 - 10sec
Sets the duration to determine
whether the input analog audio is
silent.
SILENCE LVL
-72dBFS
-72 - -48dBFS
(6dBFS Step)
Sets the audio level to determine
whether the input analog audio is
silent.
Menu button
CONV1
ANALOG
Menu button
CONV1
ANALOG
