UNIT ALARM
VIDEO IN STATUS
VIDEO OP INPUT
*1*2
VIDEO OUT STATUS
VIDEO OP OUTPUT
*1*2
AUDIO IN DETECT1
AUDIO IN DETECT2
AUDIO OUTPUT1
AUDIO OUTPUT2
EMB1 IN AUDIO CH1 to 16
EMB2 IN AUDIO CH1 to 16
AES IN AUDIO CH1 to 8
ANALOG IN AUDIO CH1 to 4
SDI1/2 OUT AUDIO CH1 to 16
SDI3/4 OUT AUDIO CH1 to 16
AES OUT AUDIO CH1 to 8
ANALOG OUT AUDIO CH1 to 4
Dolby OP A AUX
*6*8
Dolby OP B AUX
*7*9
AFD IN STATUS
ANC IN STATUS
ANC IN STATUS1 to 2
ANC OUT
S2016 OUT
VI OUT
WSS OUT
ANC OUT1
*1 Shown if the optional FA-95AIO is installed in option slot A.
*2 Shown if the optional FA-95AIO is installed in option slot B.
*3 Hidden if the optional FA-95DACBL is installed.
*4 Shown if the optional FA-95ALA is installed in option slot A.
*5 Shown if the optional FA-95ALA is installed in option slot B.
*6 Shown if the optional FA-95D-D is installed in option slot A.
*7 Shown if the optional FA-95D-D is installed in option slot B.
*8 Shown if the optional FA-95DE-E is installed in option slot A.
*9 Shown if the optional FA-95DE-E is installed in option slot B.
Can be navigated to using double (up and down) arrow buttons. “ “ is not shown in the menu
display.
⊚ Settings for FS1 and FS2 can be selected or verified separately using the FS1 or FS2 button. ⊚
Can change settings for FS1 and FS2 simultaneously in LINK mode. “ “ and “⊚” are not shown in
the menu display.
● When changed in LIVE SAFE mode, single (up and down) arrow buttons and the LED around the
control knob of which setting is changed blink confirming the setting change. To set the FA-9520 to
LIVE SAFE mode, change the mode setting referring to section 7-4. “FRONT OPERATION”. “● “ is
not shown in the menu display.
