Chapter 3 ’Web User Graphical Interface’ — Operating Instructions (Tutorial)
130 Electra VS
-
Version 05.10
User Manual - Rev. A
Figure 3-69. Job panel based on a workflow where parameters are not sorted
Now hereunder the job panel based on the same workflow where
parameters are sorted. You can note that the parameters are now
regrouped in more than one section with several groups in each section
making job editing easier and most intuitive.
Figure 3-70. Job panel based on a workflow where parameters are sorted
sections groups in the selected section (‘IP input’ here)
