Keithley DMM7510 Reference Manual

Model DMM7510
7½ Digit Graphical Sampling Multimeter Reference Manual Section 3:
Functions and features
DMM7510-901-01 Rev. B / May 2015 3-17
7. Select OK. The MANAGE READING BUFFERS window is displayed, showing the buffer you just
created.
Figure 109: MANAGE READING BUFFERS window
8. Press the HOME key to return to the Home screen.
After you create a new reading buffer, the new reading buffer becomes the active buffer.
Using SCPI commands to create a reading buffer:
To create a full reading buffer named testData with a capacity of 200 readings, send the following
command:
TRACe:MAKE "testData", 200, FULL
Using TSP commands to create a reading buffer:
To create a full reading buffer named testData with a capacity of 200 readings, send the following
command:
testData = buffer.make(200, buffer.STYLE_FULL)
Setting reading buffer options
You can specify the settings for the reading buffers. The settings you can select include:
• Buffer capacity: The amount of data the buffer holds
• Buffer style: What data is returned for each buffer index
• Fill mode: How the incoming data is managed as the buffer fills

Keithley DMM7510 Specifications

General

Resolution	7.5 digits
DC Voltage Range	100 mV to 1000 V
AC Voltage Range	100 mV to 750 V
DC Current Range	10 µA to 10 A
Resistance Range	10 Ω to 1 GΩ
Sampling Rate	1 MS/s
Memory	27.5 million readings
Display	5 inch capacitive touchscreen
AC Voltage Accuracy	±0.06% of reading
AC Current Range	10 A
Connectivity	USB, LAN, GPIB
