Keithley DMM7510 Reference Manual

Model DMM7510
7½ Digit Graphical Sampling Multimeter Reference Manual Section 3:
Functions and features
DMM7510-901-01 Rev. B / May 2015 3-33
Buffer read-only attributes
Use buffer read-only attributes to access the information contained in an existing buffer.
Using SCPI commands:
The following commands are available for each reading buffer.
Attribute Description
:TRACe:ACTual?
This command contains the number of readings in the
specified buffer. See :TRACe:ACTual? (on page 6-151)
:TRACe:ACTual:END?
This command returns the last index in a reading buffer. See
:TRACe:ACTual:END? (on page 6-152).
:TRACe:ACTual:STARt?
This command returns the starting index in a reading buffer.
See :TRACe:ACTual:STARt? (on page 6-153).
:TRACe:DATA?
This command contains the readings stored in a specified
reading buffer. See :TRACe:DATA? (on page 6-155).
:TRACe:STATistics:AVERage?
This command returns average of all readings added to the
buffer. See :TRACe:STATistics:AVERage? (on page 6-166)
:TRACe:STATistics:MAXimum?
This command returns the maximum reading value added to
the buffer. See :TRACe:STATistics:MAXimum? (on page 6-
168)
:TRACe:STATistics:MINimum?
This command returns the minimum reading value added to
the buffer. See :TRACe:STATistics:MINimum? (on page 6-
169)
:TRACe:STATistics:PK2Pk?
This command returns the peak-to-peak value of all readings
added to the buffer. See :TRACe:STATistics:PK2Pk?
(on page
6-170).
:TRACe:STATistics:STDDev?
This command returns the standard deviation of all readings
added to the buffer. See :TRACe:STATistics:STDDev? (on
page 6-170).
Using TSP commands:
See printbuffer() (on page 8-232) for a list of available attributes.
Reading buffer time and date values
Time and date values are represented as a number of UTC seconds since 12:00 a.m. Jan. 1, 1970.
Use the following TSP commands to return values in the following formats:
• Hours and minutes: bufferVar.times (on page 8-38)
• UTC seconds: bufferVar.seconds (on page 8-35)
• Month, day, year, format, or to access the timestamp table: bufferVar.dates (on page 8-25)

Keithley DMM7510 Specifications

General

Resolution	7.5 digits
DC Voltage Range	100 mV to 1000 V
AC Voltage Range	100 mV to 750 V
DC Current Range	10 µA to 10 A
Resistance Range	10 Ω to 1 GΩ
Sampling Rate	1 MS/s
Memory	27.5 million readings
Display	5 inch capacitive touchscreen
AC Voltage Accuracy	±0.06% of reading
AC Current Range	10 A
Connectivity	USB, LAN, GPIB
