Keithley DMM7510 Reference Manual

Section
3: Functions and features Model DMM7510 7½ Digit Graphical Sampling Multimeter
Reference Manual
3-56 DMM7510-901-01 Rev. B / May 2015
SCPI command
TSP command Description
:DIGital:LINE<n>:MODE (on page 6-38)
This command sets the mode of the digital I/O line to
be a digital line, trigger line, or synchronous line and
sets the line to be input, output, or open-drain.
digio.line[N].mode (on page 8-52)
A line reset is not available in SCPI; however, the line is
reset when a global reset (
*RST
) is sent
This command resets digital I/O line values to their
factory defaults.
digio.line[N].reset() (on page 8-54)
:DIGital:LINE<n>:STATe (on page 6-40)
This command sets a digital I/O line high or low when
the line is set for digital control and returns the state
on the digital I/O lines.
digio.line[N].state (on page 8-55)
:DIGital:READ? (on page 6-41) This command reads the digital I/O port. All six lines
must be configured as digital control lines. If not, this
command generates an error.
digio.readport() (on page 8-55)
:DIGital:WRITe <n> (on page 6-42) This command writes to all digital I/O lines. All six
lines must be configured as digital control lines. If not,
this command generates an error.
digio.writeport() (on page 8-56)
:TRIGger:DIGital<n>:IN:CLEar (on page 6-204) This command clears the trigger event on a digital
input line.
trigger.digin[N].clear() (on page 8-260)
:TRIGger:DIGital<n>:IN:EDGE (on page 6-204)
This command sets the edge used by the trigger
event detector on the given trigger line.
trigger.digin[N].edge (on page 8-260)
:TRIGger:DIGital<n>:IN:OVERrun? (on page 6-205)
This command returns the event detector overrun
status.
trigger.digin[N].overrun (on page 8-261)
Not available in SCPI
This command waits for a trigger.
trigger.digin[N].wait() (on page 8-262)
Not available in SCPI
This command asserts a trigger pulse on one of the
digital I/O lines.
trigger.digout[N].assert() (on page 8-263)
:TRIGger:DIGital<n>:OUT:LOGic (on page 6-206)
This command sets the output logic of the trigger
event generator to positive or negative for the
specified line.
trigger.digout[N].logic (on page 8-264)
:TRIGger:DIGital<n>:OUT:PULSewidth (on page 6-207)
This command describes the length of time that the
trigger line is asserted for output triggers.
trigger.digout[N].pulsewidth (on page 8-264)
Not available in SCPI
This command releases an indefinite length or
latched trigger.
trigger.digout[N].release() (on page 8-265)
:TRIGger:DIGital<n>:OUT:STIMulus (on page 6-208)
This command selects the event that causes a trigger
to be asserted on the digital output line.
trigger.digout[N].stimulus (on page 8-266)

Keithley DMM7510 Specifications

General

Resolution	7.5 digits
DC Voltage Range	100 mV to 1000 V
AC Voltage Range	100 mV to 750 V
DC Current Range	10 µA to 10 A
Resistance Range	10 Ω to 1 GΩ
Sampling Rate	1 MS/s
Memory	27.5 million readings
Display	5 inch capacitive touchscreen
AC Voltage Accuracy	±0.06% of reading
AC Current Range	10 A
Connectivity	USB, LAN, GPIB
