Keithley DMM7510 Reference Manual

Model DMM7510
7½ Digit Graphical Sampling Multimeter Reference Manual Section 3:
Functions and features
DMM7510-901-01 Rev. B / May 2015 3-75
You can use some trigger objects to generate output triggers on demand. These trigger objects are
the external I/O line, digital I/O lines, the TSP-Link synchronization lines, and the LAN.
The programming example below generates output triggers using the assert function of the trigger
object.
-- Generate a 20 us pulse on digital I/O line 3.
digio.line[3].mode = digio.MODE_TRIGGER_OUT
trigger.digout[3].pulsewidth = 20e-6
trigger.digout[3].assert()
-- Generate a rising edge trigger on TSP-Link sync line 1.
tsplink.line[1].mode = tsplink.MODE_TRIGGER_OPEN_DRAIN
trigger.tsplinkin[1].edge = trigger.EDGE_RISING
trigger.tsplinkout[1].logic = trigger.LOGIC_POSITIVE
trigger.tsplinkout[1].assert()
-- Generate a LAN trigger on LAN pseudo line 6.
-- Note that connection parameters and commands that
-- establish a connection are not shown.
trigger.lanout[6].assert()
Use the release function to allow the hardware line to output another external trigger when the pulse
width is set to 0.
Setting the pulse width to 0 results in an indefinite length pulse when the assert function is used to
output an external trigger. When an indefinite length pulse is used, the release function must be used
to release the line before another external trigger can be output.
The release function can also be used to release latched input triggers when the hardware line mode
is set to synchronous. In synchronous mode, the receipt of a falling edge trigger latches the line low.
The release function releases this line high in preparation for another input trigger.
The programming example below illustrates how to output an indefinite external trigger.
-- Set digio line 1 to output an indefinite external trigger.
digio.line[1].mode = digio.MODE_TRIGGER_OUT
trigger.digout[1].logic = trigger.LOGIC_NEGATIVE
trigger.digout[1].pulsewidth = 0
trigger.digout[1].assert()
-- Release digio line 1.
trigger.digout[1].release()
-- Output another external trigger.
trigger.digout[1].assert()
For information about hardware lines, see Digital I/O lines (on page 3-51) , External I/O (on page 3-
59), and Triggering using TSP-Link synchronization lines (on page 3-109).
The programming example below checks and responds to detector overruns.
testOver = trigger.digin[4].overrun
if testOver == true then
print("Digital I/O overrun occurred.")
end

Keithley DMM7510 Specifications

General

Resolution	7.5 digits
DC Voltage Range	100 mV to 1000 V
AC Voltage Range	100 mV to 750 V
DC Current Range	10 µA to 10 A
Resistance Range	10 Ω to 1 GΩ
Sampling Rate	1 MS/s
Memory	27.5 million readings
Display	5 inch capacitive touchscreen
AC Voltage Accuracy	±0.06% of reading
AC Current Range	10 A
Connectivity	USB, LAN, GPIB
