6: SCPI command reference Model DMM7510 7½ Digit Graphical Sampling Multimeter
Reference Manual
6-186 DMM7510-901-01 Rev. B / May 2015
The following table shows the constants for the events.
Trigger events
Event description Event constant
No trigger event
NONE
Front-panel TRIGGER key press
DISPlay
Notify trigger block <n> (1 to 8); the trigger model generates a
trigger event when it executes the notify block
NOTify<n>
A command interface trigger (bus trigger):
• Any remote interface: *TRG
• GPIB only: GET bus command
• VXI-11: VXI-11 command
device_trigger
COMMand
Line edge (either rising, falling, or either based on the
configuration of the line) detected on digital input line <n> (1 to 6)
DIGio<n>
Line edge detected on TSP-Link synchronization line <n> (1 to 3)
TSPLink<n>
Appropriate LXI trigger packet is received on LAN trigger object
<n>
(1 to 8)
LAN<n>
Trigger event blender
<n>
(1 or 2), which combines trigger events
BLENder<n>
Trigger timer <n> (1 to 4) expired
TIMer<n>
Analog trigger
ATRigger
External in trigger
EXTernal
Example
:TRIG:BLOC:BRAN:EVEN 6, DISP, 2
When the trigger model reaches this block, if the front-panel TRIGGER key has been pressed, the trigger
model returns to block 2. If the TRIGGER key has not been pressed, the trigger model continues to block 7
(the next block in the trigger model).
Also see
On event block (on page 3-88)
