Keithley DMM7510 Reference Manual

Model DMM7510
7½ Digit Graphical Sampling Multimeter Reference Manual Section 2:
General operation
DMM7510-901-01 Rev. B / May 2015 2-31
Temperature measure settings
The following options are available on the Measure Settings menu when the function is set to
Temperature.
Setting Description
Unit
Set the type of units that are displayed on the front panel and
stored with the temperature measurement in the reading buffer.
Auto Delay
Applies a wait period at the start of measurement to allow cables
and circuitry to settle for best accuracy. Refer to Auto Delay
(on
page 2-137).
Display Digits
Always set to 5.5 digits for temperature.
Transducer
Sets the type of transducer that is used to temperature
measurements.
Integration Rate
Controls the amount of time the input signal is measured
(aperture), which affects the noise and reading rate; see Using
aperture or NPLCs to adjust speed and accuracy (on page 4-1).
Auto Zero
Determines if internal reference points are used to maintain
stability and accuracy. See Automatic reference measurements (on
page 2-149).
Count
Sets the number of aperture readings that are processed when a
measurement is requested.
Line Sync
Enables or disables line synchronization. When it is enabled, it
helps increase common-mode and normal-mode noise rejection.
Refer to Line cycle synchronization (on page 4-1).
Thermocouple
Thermocouple only. Sets the thermocouple type.
Temperature
Thermocouple only: The simulated reference temperature.
Open Lead Detector
Thermocouple and RTDs only: Enables or disables open lead
detection. When enabled, detects open test leads.
Reference Junction
Thermocouple only: Displays Simulated.
Thermistor
Thermistor only: Sets the type of thermistor.
RTD Type
RTD only: Sets the RTD type. See RTDs (Resistance Temperature
Detectors).
Offset Compensation
RTD only: Enables or disables offset compensation.
RTD Alpha
RTD only when USER is selected: Sets the alpha value of a
user-defined RTD.
RTD Beta
RTD only when USER is selected: Sets the beta value of a
user-defined RTD.
RTD Delta
RTD only when USER is selected: Sets the delta value of a
user-defined RTD.
RTD Zero
RTD only when USER is selected: Sets the zero value of a
user-defined RTD.
