Keithley DMM7510 Reference Manual

Model DMM7510
7½ Digit Graphical Sampling Multimeter Reference Manual Section 2:
General operation
DMM7510-901-01 Rev. B / May 2015 2-35
Setting Description
Zero Reference
When the Math State is set to On, this setting specifies the
reference used when the math operation is set to percent; the
range is -1e12 to +1e12.
Limit 1 and Limit 2
These settings enable or disable limit testing. The Limit options
allow you to do pass-or-fail limit testing using the front panel of the
instrument. When you do a limit test, the Home screen displays the
pass or fail result of the test.
Limit State enables or disables a limit test for the selected
measurement function. When testing is enabled, limit testing
occurs on each measurement. Limit testing compares the
measurements to the high and low limit values. If a measurement
is outside these limits, the test fails. If a measurement is in the
limits, it passes.
Config
Displays the settings that are available for the limit functions.
Auto Clear
Auto clear indicates if the high and low limits should be cleared
automatically or not.
Low Value
The Low Value specifies the lower limit for limit tests.
High Value
The Limit High Level specifies the upper limit for a limit test.
Audible
Audible determines if the instrument beeper sounds when a limit
test passes or fails, or disables the beeper.

Keithley DMM7510 Specifications

General

Resolution	7.5 digits
DC Voltage Range	100 mV to 1000 V
AC Voltage Range	100 mV to 750 V
DC Current Range	10 µA to 10 A
Resistance Range	10 Ω to 1 GΩ
Sampling Rate	1 MS/s
Memory	27.5 million readings
Display	5 inch capacitive touchscreen
AC Voltage Accuracy	±0.06% of reading
AC Current Range	10 A
Connectivity	USB, LAN, GPIB
