Keithley DMM7510 Reference Manual

Section
2: General operation Model DMM7510 7½ Digit Graphical Sampling Multimeter
Reference Manual
2-36 DMM7510-901-01 Rev. B / May 2015
Measure Config Lists menu
The Config Lists menu allows you to select an existing measure
configuration list, create a new list, load configuration settings to and from
the instrument (system), and view the settings of an index in a
configuration list. For more information about using configuration lists, see
Configuration lists (on page 3-37
).
Setting Description
Select List
Displays a list of available configuration lists from which you can
choose.
New List
Creates a new, empty configuration list. To populate the list with
the present instrument settings, select System to Index.
Delete Index
Deletes a configuration list index from the selected configuration
list.
System to Index
Saves the present instrument settings to an index at the end of the
selected configuration list.
Index to System
Restores the instrument to the settings stored in the selected
configuration list index.
Index Details
Displays the details of the selected configuration index. Details
include settings such as function, value, delay, calculations, and
range. You can scroll the displayed list to view additional settings.

Keithley DMM7510 Specifications

General

Resolution	7.5 digits
DC Voltage Range	100 mV to 1000 V
AC Voltage Range	100 mV to 750 V
DC Current Range	10 µA to 10 A
Resistance Range	10 Ω to 1 GΩ
Sampling Rate	1 MS/s
Memory	27.5 million readings
Display	5 inch capacitive touchscreen
AC Voltage Accuracy	±0.06% of reading
AC Current Range	10 A
Connectivity	USB, LAN, GPIB
