100 Keysight InfiniiVision DSOX1204A/G Oscilloscopes Programmer's Guide
4 Commands Quick Reference
:WGEN:MODulation:AM:F
REQuency <frequency>
(see page 680)
:WGEN:MODulation:AM:F
REQuency? (see
page 680)
<frequency> ::= modulating
waveform frequency in Hz in NR3
format
:WGEN:MODulation:FM:D
EViation <frequency>
(see page 681)
:WGEN:MODulation:FM:D
EViation? (see
page 681)
<frequency> ::= frequency
deviation in Hz in NR3 format
:WGEN:MODulation:FM:F
REQuency <frequency>
(see page 682)
:WGEN:MODulation:FM:F
REQuency? (see
page 682)
<frequency> ::= modulating
waveform frequency in Hz in NR3
format
:WGEN:MODulation:FSKe
y:FREQuency <percent>
(see page 683)
:WGEN:MODulation:FSKe
y:FREQuency? (see
page 683)
<frequency> ::= hop frequency in
Hz in NR3 format
:WGEN:MODulation:FSKe
y:RATE <rate> (see
page 684)
:WGEN:MODulation:FSKe
y:RATE? (see page 684)
<rate> ::= FSK modulation rate in
Hz in NR3 format
:WGEN:MODulation:FUNC
tion <shape> (see
page 685)
:WGEN:MODulation:FUNC
tion? (see page 685)
<shape> ::= {SINusoid | SQUare|
RAMP}
:WGEN:MODulation:FUNC
tion:RAMP:SYMMetry
<percent> (see
page 686)
:WGEN:MODulation:FUNC
tion:RAMP:SYMMetry?
(see page 686)
<percent> ::= symmetry
percentage from 0% to 100% in NR1
format
:WGEN:MODulation:NOIS
e <percent> (see
page 687)
:WGEN:MODulation:NOIS
e? (see page 687)
<percent> ::= 0 to 100
:WGEN:MODulation:STAT
e {{0 | OFF} | {1 |
ON}} (see page 688)
:WGEN:MODulation:STAT
e? (see page 688)
{0 | 1}
:WGEN:MODulation:TYPE
<type> (see page 689)
:WGEN:MODulation:TYPE
? (see page 689)
<type> ::= {AM | FM | FSK}
:WGEN:OUTPut {{0 |
OFF} | {1 | ON}} (see
page 691)
:WGEN:OUTPut? (see
page 691)
{0 | 1}
:WGEN:OUTPut:LOAD
<impedance> (see
page 692)
:WGEN:OUTPut:LOAD?
(see page 692)
<impedance> ::= {ONEMeg | FIFTy}
:WGEN:OUTPut:POLarity
<polarity> (see
page 693)
:WGEN:OUTPut:POLarity
? (see page 693)
<polarity> ::= {NORMal |
INVerted}
Table 37 :WGEN Commands Summary (continued)
Command Query Options and Query Returns
