:MEASure:XMAX
(see page 798)
Command Syntax
:MEASure:XMAX [<source>]
<source> ::= {CHANnel<n> | FUNCtion | MATH | WMEMory<r>}
<n> ::= 1-2 or 1-4 (# of analog channels) in NR1 format
<r> ::= 1-2 in NR1 format
The :MEASure:XMAX command installs a screen measurement and starts an
X-at-Max-Y measurement on the selected window. If the optional source
parameter is specified, the current source is modified.
Query Syntax
:MEASure:XMAX? [<source>]
The :MEASure:XMAX? query measures and returns the horizontal axis value at
which the maximum vertical value occurs. If the optional source is specified, the
current source is modified.
Return Format
<value><NL>
<value> ::= horizontal value of the maximum in NR3 format
See Also • "Introduction to :MEASure Commands" on page 350
• ":MEASure:XMIN" on page 397
• ":MEASure:TMAX" on page 735
NOTE
:MEASure:XMAX is an alias for :MEASure:TMAX.
