:SBUS<n> Commands 24
Keysight InfiniiVision DSOX1204A/G Oscilloscopes Programmer's Guide 523
:SBUS<n>:UART Commands
These commands are valid when the UART/RS-232 triggering and serial decode license
(EMBD) is enabled.
Table 74 :SBUS<n>:UART Commands Summary
Command Query Options and Query Returns
:SBUS<n>:UART:BASE
<base> (see page 525)
:SBUS<n>:UART:BASE?
(see page 525)
<base> ::= {ASCii | BINary | HEX}
:SBUS<n>:UART:BAUDrat
e <baudrate> (see
page 526)
:SBUS<n>:UART:BAUDrat
e? (see page 526)
<baudrate> ::= integer from 100
to 8000000
:SBUS<n>:UART:BITorde
r <bitorder> (see
page 527)
:SBUS<n>:UART:BITorde
r? (see page 527)
<bitorder> ::= {LSBFirst |
MSBFirst}
n/a :SBUS<n>:UART:COUNt:E
RRor? (see page 528)
<frame_count> ::= integer in NR1
format
:SBUS<n>:UART:COUNt:R
ESet (see page 529)
n/a n/a
n/a :SBUS<n>:UART:COUNt:R
XFRames? (see
page 530)
<frame_count> ::= integer in NR1
format
n/a :SBUS<n>:UART:COUNt:T
XFRames? (see
page 531)
<frame_count> ::= integer in NR1
format
:SBUS<n>:UART:FRAMing
<value> (see page 532)
:SBUS<n>:UART:FRAMing
? (see page 532)
<value> ::= {OFF | <decimal> |
<nondecimal>}
<decimal> ::= 8-bit integer from
0-255 (0x00-0xff)
<nondecimal> ::= #Hnn where n ::=
{0,..,9 | A,..,F} for hexadecimal
<nondecimal> ::= #Bnn...n where n
::= {0 | 1} for binary
:SBUS<n>:UART:PARity
<parity> (see
page 533)
:SBUS<n>:UART:PARity?
(see page 533)
<parity> ::= {EVEN | ODD | NONE}
:SBUS<n>:UART:POLarit
y <polarity> (see
page 534)
:SBUS<n>:UART:POLarit
y? (see page 534)
<polarity> ::= {HIGH | LOW}
