524 Keysight InfiniiVision DSOX1204A/G Oscilloscopes Programmer's Guide
24 :SBUS<n> Commands
:SBUS<n>:UART:SOURce:
RX <source> (see
page 535)
:SBUS<n>:UART:SOURce:
RX? (see page 535)
<source> ::= {CHANnel<n>}
<n> ::= 1 to (# analog channels)
in NR1 format
:SBUS<n>:UART:SOURce:
TX <source> (see
page 536)
:SBUS<n>:UART:SOURce:
TX? (see page 536)
<source> ::= {CHANnel<n>}
<n> ::= 1 to (# analog channels)
in NR1 format
:SBUS<n>:UART:TRIGger
:BASE <base> (see
page 537)
:SBUS<n>:UART:TRIGger
:BASE? (see page 537)
<base> ::= {ASCii | HEX}
:SBUS<n>:UART:TRIGger
:BURSt <value> (see
page 538)
:SBUS<n>:UART:TRIGger
:BURSt? (see page 538)
<value> ::= {OFF | 1 to 4096 in
NR1 format}
:SBUS<n>:UART:TRIGger
:DATA <value> (see
page 539)
:SBUS<n>:UART:TRIGger
:DATA? (see page 539)
<value> ::= 8-bit integer from
0-255 (0x00-0xff) in decimal,
<hexadecimal>, <binary>, or
<quoted_string> format
<hexadecimal> ::= #Hnn where n
::= {0,..,9 | A,..,F} for
hexadecimal
<binary> ::= #Bnn...n where n ::=
{0 | 1} for binary
<quoted_string> ::= any of the
128 valid 7-bit ASCII characters
(or standard abbreviations)
:SBUS<n>:UART:TRIGger
:IDLE <time_value>
(see page 540)
:SBUS<n>:UART:TRIGger
:IDLE? (see page 540)
<time_value> ::= time from 1 us
to 10 s in NR3 format
:SBUS<n>:UART:TRIGger
:QUALifier <value>
(see page 541)
:SBUS<n>:UART:TRIGger
:QUALifier? (see
page 541)
<value> ::= {EQUal | NOTequal |
GREaterthan | LESSthan}
:SBUS<n>:UART:TRIGger
:TYPE <value> (see
page 542)
:SBUS<n>:UART:TRIGger
:TYPE? (see page 542)
<value> ::= {RSTArt | RSTOp |
RDATa | RD1 | RD0 | RDX |
PARityerror | TSTArt | TSTOp |
TDATa | TD1 | TD0 | TDX}
:SBUS<n>:UART:WIDTh
<width> (see page 543)
:SBUS<n>:UART:WIDTh?
(see page 543)
<width> ::= {5 | 6 | 7 | 8 | 9}
Table 74 :SBUS<n>:UART Commands Summary (continued)
Command Query Options and Query Returns
