:WGEN Commands 29
Keysight InfiniiVision DSOX1204A/G Oscilloscopes Programmer's Guide 673
:WGEN:FUNCtion
(see page 798)
Command Syntax
:WGEN:FUNCtion <signal>
<signal> ::= {SINusoid | SQUare | RAMP | PULSe | NOISe | DC}
The :WGEN:FUNCtion command selects the type of waveform:
Waveform
Type
Characteristics
SINusoid Use these commands to set the sine signal parameters:
• ":WGEN:FREQuency" on page 672
• ":WGEN:PERiod" on page 694
• ":WGEN:VOLTage" on page 696
• ":WGEN:VOLTage:OFFSet" on page 699
• ":WGEN:VOLTage:HIGH" on page 697
• ":WGEN:VOLTage:LOW" on page 698
The frequency can be adjusted from 100 mHz to 20 MHz.
SQUare Use these commands to set the square wave signal parameters:
• ":WGEN:FREQuency" on page 672
• ":WGEN:PERiod" on page 694
• ":WGEN:VOLTage" on page 696
• ":WGEN:VOLTage:OFFSet" on page 699
• ":WGEN:VOLTage:HIGH" on page 697
• ":WGEN:VOLTage:LOW" on page 698
• ":WGEN:FUNCtion:SQUare:DCYCle" on page 678
The frequency can be adjusted from 100 mHz to 10 MHz.
The duty cycle can be adjusted from 20% to 80%.
