:TRIGger[:EDGE] Commands
Table 78 :TRIGger[:EDGE] Commands Summary
Command Query Options and Query Returns
:TRIGger[:EDGE]:COUPl
ing {AC | DC |
LFReject} (see
page 598)
:TRIGger[:EDGE]:COUPl
ing? (see page 598)
{AC | DC | LFReject}
:TRIGger[:EDGE]:LEVel
<level> [,<source>]
(see page 599)
:TRIGger[:EDGE]:LEVel
? [<source>] (see
page 599)
For internal triggers, <level>
::= .75 x full-scale voltage from
center screen in NR3 format.
For external triggers, <level>
::= ±(external range setting) in
NR3 format.
<source> ::= {CHANnel<n> |
EXTernal}
<n> ::= 1 to (# analog channels)
in NR1 format
:TRIGger[:EDGE]:REJec
t {OFF | LFReject |
HFReject} (see
page 600)
:TRIGger[:EDGE]:REJec
t? (see page 600)
{OFF | LFReject | HFReject}
:TRIGger[:EDGE]:SLOPe
<polarity> (see
page 601)
:TRIGger[:EDGE]:SLOPe
? (see page 601)
<polarity> ::= {POSitive |
NEGative | EITHer | ALTernate}
:TRIGger[:EDGE]:SOURc
e <source> (see
page 602)
:TRIGger[:EDGE]:SOURc
e? (see page 602)
<source> ::= {CHANnel<n> |
EXTernal | LINE | WGEN}
<n> ::= 1 to (# analog channels)
in NR1 format
