:MEASure Commands 20
Keysight InfiniiVision DSOX1204A/G Oscilloscopes Programmer's Guide 397
:MEASure:XMIN
(see page 798)
Command Syntax
:MEASure:XMIN [<source>]
<source> ::= {CHANnel<n> | FUNCtion | MATH | WMEMory<r>}
<n> ::= 1-2 or 1-4 (# of analog channels) in NR1 format
<r> ::= 1-2 in NR1 format
The :MEASure:XMIN command installs a screen measurement and starts an
X-at-Min-Y measurement on the selected window. If the optional source
parameter is specified, the current source is modified.
Query Syntax
:MEASure:XMIN? [<source>]
The :MEASure:XMIN? query measures and returns the horizontal axis value at
which the minimum vertical value occurs. If the optional source is specified, the
current source is modified.
Return Format
<value><NL>
<value> ::= horizontal value of the minimum in NR3 format
See Also • "Introduction to :MEASure Commands" on page 350
• ":MEASure:XMAX" on page 396
• ":MEASure:TMIN" on page 736
:MEASure:XMIN is an alias for :MEASure:TMIN.
