Obsolete and Discontinued Commands 31

Keysight InfiniiVision DSOX1204A/G Oscilloscopes Programmer's Guide 721

:ERASe

(see page 798)

Command Syntax

:ERASe

The :ERASe command erases the screen.

NOTE

The :ERASe command is an obsolete command provided for compatibility to previous

oscilloscopes. Use the :DISplay:CLEar command (see page 233) instead.
