366 Keysight InfiniiVision DSOX1204A/G Oscilloscopes Programmer's Guide
20 :MEASure Commands
:MEASure:NPULses
(see page 798)
Command Syntax
:MEASure:NPULses [<source>]
<source> ::= {CHANnel<n> | FUNCtion | MATH | WMEMory<r>}
<n> ::= 1 to (# analog channels) in NR1 format
<r> ::= 1-2 in NR1 format
The :MEASure:NPULses command installs a falling pulse count measurement on
screen. If the optional source parameter is not specified, the current source is
measured.
Query Syntax
:MEASure:NPULses? [<source>]
The :MEASure:NPULses? query measures and returns the on-screen falling pulse
count.
Return Format
<value><NL>
<value> ::= the falling pulse count in NR3 format
See Also • "Introduction to :MEASure Commands" on page 350
• ":MEASure:SOURce" on page 380
This command is not available if the source is FFT (Fast Fourier Transform).
