742 Keysight InfiniiVision DSOX1204A/G Oscilloscopes Programmer's Guide
31 Obsolete and Discontinued Commands
:MEASure:VSTArt
(see page 798)
Command Syntax
:MEASure:VSTArt <vstart_argument>
<vstart_argument> ::= value for vertical marker 1
The :MEASure:VSTArt command moves the vertical marker (Y1 cursor) to the
specified value corresponding to the selected source. The source can be selected
by the MARKer:X1Y1source command.
Query Syntax
:MEASure:VSTArt?
The :MEASure:VSTArt? query returns the current value of the Y1 cursor.
Return Format
<value><NL>
<value> ::= voltage at voltage marker 1 in NR3 format
See Also • "Introduction to :MARKer Commands" on page 326
• "Introduction to :MEASure Commands" on page 350
• ":MARKer:Y1Position" on page 336
• ":MARKer:Y2Position" on page 337
• ":MARKer:YDELta" on page 338
• ":MARKer:X1Y1source" on page 330
• ":MEASure:SOURce" on page 380
• ":MEASure:TDELta" on page 733
• ":MEASure:TSTArt" on page 737
The short form of this command, VSTA, does not follow the defined Long Form to Short Form
Truncation Rules (see page 800). The normal short form, VST, would be the same for both
VSTArt and VSTOp, so sending VST for the VSTArt command produces an error.
The :MEASure:VSTArt command is an obsolete command provided for compatibility to
previous oscilloscopes. Use the :MARKer:Y1Position command (see page 336) instead.
