:SBUS<n> Commands 24

Keysight InfiniiVision DSOX1204A/G Oscilloscopes Programmer's Guide 517

:SBUS<n>:SPI:TRIGger:PATTern:MISO:DATA

(see page 798)

Command Syntax

:SBUS<n>:SPI:TRIGger:PATTern:MISO:DATA <string>

<string> ::= "nn...n" where n ::= {0 |1|X|$}

<string ::= "0xnn...n" where n ::= {0,..,9 | A,..,F | X | $}

The :SBUS<n>:SPI:TRIGger:PATTern:MISO:DATA command defines the SPI data

pattern resource according to the string parameter. This pattern, along with the

data width, control the data pattern searched for in the data stream.

If the string parameter starts with "0x", it is a hexadecimal string made up of

hexadecimal and X (don't care) characters; otherwise, it is a binary string made up

of 0, 1, and X (don't care) characters.

Query Syntax

:SBUS<n>:SPI:TRIGger:PATTern:MISO:DATA?

The :SBUS<n>:SPI:TRIGger:PATTern:MISO:DATA? query returns the current

settings of the specified SPI data pattern resource in the binary string format.

Return Format

See Also • "Introduction to :TRIGger Commands" on page 585

• ":SBUS<n>:SPI:TRIGger:PATTern:MISO:WIDTh" on page 518

• ":SBUS<n>:SPI:SOURce:MISO" on page 515

NOTE

The :SBUS<n>:SPI:TRIGger:PATTern:MISO:WIDTh should be set before

:SBUS<n>:SPI:TRIGger:PATTern:MISO:DATA.
