Keysight InfiniiVision DSOX1204A/G Oscilloscopes
Programmer's Guide
16 :FRANalysis Commands
Control oscilloscope functions associated with the Frequency Response Analysis
(FRA) feature, which is available in G-suffix oscilloscope models (that have a
built-in waveform generator). See "Introduction to :FRANalysis Commands" on
page 274.
Table 61 :FRANalysis Commands Summary
Command Query Options and Query Returns
n/a :FRANalysis:DATA?
(see page 275)
<binary_block> ::=
comma-separated data with
newlines at the end of each row
:FRANalysis:ENABle
{{0 | OFF} | {1 |
ON}} (see page 276)
:FRANalysis:ENABle?
(see page 276)
{0 | 1}
:FRANalysis:FREQuency
:MODE <setting> (see
page 277)
:FRANalysis:FREQuency
:MODE? (see page 277)
<setting> ::= {SWEep | SINGle}
:FRANalysis:FREQuency
:SINGle
<value>[suffix] (see
page 278)
:FRANalysis:FREQuency
:SINGle? (see
page 278)
<value> ::= between 10 Hz and
20 MHz with a resolution of
0.1 Hz in NR3 format
[suffix] ::= {Hz | kHz| MHz}
:FRANalysis:FREQuency
:STARt
<value>[suffix] (see
page 279)
:FRANalysis:FREQuency
:STARt? (see page 279)
<value> ::= between 10 Hz and
19.99 MHz with a resolution of
0.1 Hz in NR3 format
[suffix] ::= {Hz | kHz| MHz}
:FRANalysis:FREQuency
:STOP <value>[suffix]
(see page 280)
:FRANalysis:FREQuency
:STOP? (see page 280)
<value> ::= between 10.1 Hz and
20 MHz with a resolution of
0.1 Hz in NR3 format
[suffix] ::= {Hz | kHz| MHz}
:FRANalysis:RUN (see
page 281)
n/a n/a
