732 Keysight InfiniiVision DSOX1204A/G Oscilloscopes Programmer's Guide

31 Obsolete and Discontinued Commands

:MEASure:SCRatch

(see page 798)

Command Syntax

:MEASure:SCRatch

The :MEASure:SCRatch command clears all selected measurements and markers

from the screen.

NOTE

The :MEASure:SCRatch command is obsolete and is provided for backward compatibility to

previous oscilloscopes. Use the :MEASure:CLEar command (see page 354) instead.
