Keysight InfiniiVision DSOX1204A/G Oscilloscopes
Programmer's Guide
13 :DVM Commands
When the optional DSOXDVM digital voltmeter analysis feature is licensed, these
commands control the digital voltmeter (DVM) feature.
Table 58 :DVM Commands Summary
Command Query Options and Query Returns
:DVM:ARANge {{0 |
OFF} | {1 | ON}} (see
page 242)
:DVM:ARANge? (see
page 242)
{0 | 1}
n/a :DVM:CURRent? (see
page 243)
<dvm_value> ::= floating-point
number in NR3 format
:DVM:ENABle {{0 |
OFF} | {1 | ON}} (see
page 244)
:DVM:ENABle? (see
page 244)
{0 | 1}
n/a :DVM:FREQuency? (see
page 243)
<freq_value> ::= floating-point
number in NR3 format
:DVM:MODE <mode> (see
page 246)
:DVM:MODE? (see
page 246)
<dvm_mode> ::= {ACRMs | DC |
DCRMs | FREQuency}
:DVM:SOURce <source>
(see page 247)
:DVM:SOURce? (see
page 247)
<source> ::= {CHANnel<n>}
<n> ::= 1 to (# analog channels)
in NR1 format
