:DEMO Commands 11
Keysight InfiniiVision DSOX1204A/G Oscilloscopes Programmer's Guide 225
Query Syntax :DEMO:FUNCtion?
The :DEMO:FUNCtion? query returns the currently selected demo signal type.
Return Format
<signal><NL>
<signal> ::= {SIN | NOIS | LFS | AM | RFB | FMB | HARM | COUP | RING
| SING | CLK | TRAN | BURS | GLIT | UART | CAN | LIN}
See Also • "Introduction to :DEMO Commands" on page 223
UART Receive data (RX) with odd parity, 19.2 kbps, 8-bit words, LSB out
1st, low idle @ ~2.8 Vpp, 1.4 V offset
CAN CAN_L, 125 kbps dominant-low, ~2.8 Vpp, ~1.4 V offset, available
in DSOX1000-Series oscilloscope models only
LIN LIN, 19.2 kbs, ~2.8 Vpp, ~1.4 V offset, available in
DSOX1000-Series oscilloscope models only
Demo Signal Function Demo Terminal
